UBIQUITY UniFi 7 Pro | WiFi 7 Access Point | US Model | PoE+ Adapter not Included (U7-Pro-US)

The Ubiquiti UniFi U7 Pro is a ceiling-mount, high-density WiFi 7 (802.11be) access point that delivers ultra-fast, low-latency wireless connectivity in demanding, large-scale installations. With the 6 GHz band, six spatial streams, and a 2.5 GbE uplink, it delivers seamless connectivity to over 300 concurrent devices.

Key Specifications

WiFi Standards: 802.11a/b/g/n/ac/ax/be (WiFi 7)

Bands: Tri-band (2.4 GHz, 5 GHz, 6 GHz)

MIMO Configuration: 2×2 MU-MIMO per band

Maximum Data Rates:

• 2.4 GHz: 688 Mbps
• 5 GHz: 2.88 Gbps
• 6 GHz: 5.77 Gbps

Total Throughput: Up to 9.3 Gbps

Coverage Area: Up to 140 m² (1,500 ft²)

Concurrent Clients: Supports 300+ devices

Antenna Gain:

• 2.4 GHz: 4 dBi
• 5 GHz: 6 dBi
• 6 GHz: 5.8 dBi

Transmit Power:

• 2.4 GHz: 22 dBm
• 5 GHz: 26 dBm
• 6 GHz: 23 dBm

Networking Interface: (1) 2.5 GbE RJ45 port (PoE+)

Power Method: Power over Ethernet Plus (PoE+), 802.3at

Max Power Consumption: ≤21W

Mounting Options: Wall and ceiling mounts included

Operating Temperature: -30 to 60°C (-22 to 140°F)

Operating Humidity: 5% to 95% noncondensing

Dimensions: Ø206 x 46 mm (Ø8.1 x 1.8″)

Weight: 680 g (1.5 lb)

Key Features

• WiFi 7 Technology: Enhanced performance and efficiency with support for the 6 GHz band, delivering interference-free connectivity.
• High Client Capacity: Manages more than 300 simultaneously connected devices, ideal for high-density deployments.
• Advanced Security: WPA3, WPA2, and WPA-Enterprise encryption standards supported.
• Guest Network Features: Captive portal, guest isolation, and voucher-based authentication are supported.
• Flexible Mounting: Mountable on the ceiling or wall, with mounting hardware included.
• Efficient Power Usage: Low power consumption with PoE+ support makes installation straightforward.​

Technical Details

Supported WiFi Standards: 802.11a/b/g/n/ac/ax/be

Channel Bandwidths: HT20/40, VHT20/40/80/160, HE20/40/80/160, EHT20/40/80/160/240/320 MHz

Advanced Features:

• Band Steering
• Fast Roaming (802.11r)
• BSS Transition Management (802.11v)
• Radio Resource Management (802.11k)
• Private Pre-Shared Key (PPSK)
• Dynamic VLAN assignment with RADIUS
• WiFi scheduling and client device isolation
• Captive portal with custom branding and voucher authentication
• Guest network isolation and WiFi speed limiting

Package Contents

• Ubiquiti UniFi U7 Pro Access Point
• Ceiling and wall mounting hardware

Use Cases

• Enterprise Environments: Ideal for offices, campuses, and commercial environments that require high-capacity wireless coverage.
• Educational Institutions: Ideal for high-density client environments like classrooms and lecture theatres.
• Hospitality: Suitable for hotels and resorts that need feature-rich, secure guest WiFi.
• Retail Spaces: Offers customers a good experience with stable and fast wireless connectivity.
