UBIQUITI UNIFI AC MESH

Key Specifications

Wi-Fi Standard: 802.11ac (Wi-Fi 5)

Dual-Band Support: 2.4 GHz (up to 300 Mbps) & 5 GHz (up to 867 Mbps)

Total Aggregate Throughput: 1.1 Gbps

MIMO Configuration: 2×2 MIMO with DL MU-MIMO

Antenna Gain:

• 2.4 GHz: 3 dBi
• 5 GHz: 4 dBi

Maximum TX Power: 20 dBm (both bands)

Coverage Area: Up to 140 m² (1,500 ft²)

Client Capacity: Supports 200+ simultaneous clients

Mounting Options: Wall, Pole, or Fast-Mount (all accessories included)

Power Supply: PoE (Power over Ethernet)

Weather Resistance: IPX4-rated housing for indoor and outdoor use

Dimensions: 353 x 46 x 34.4 mm (13.9 x 1.8 x 1.4″)

Features & Capabilities

• Wireless Meshing: Seamless integration into existing UniFi networks with wireless meshing.
• Band Steering: Automatically transfers clients to the optimal band for improved performance.
• Fast Roaming: 802.11r support for quick transitions between access points.
• Radio Resource Management (RRM): Dynamic adjustment of channels and power settings to mitigate interference.
• UniFi Controller Integration: Manage and monitor your network with the UniFi Controller software, available in any standard web browser or the UniFi mobile app (iOS or Android).
• Plug-and-Play Setup: Easy installation with automatic UAP device detection and configuration.​

Use Cases

• Outdoor Wi-Fi Coverage: Ideal for providing reliable Wi-Fi in outdoor areas such as courtyards, parking lots, and public areas.
• High-Density Areas: Perfect for environments like stadiums, campuses, and event centers that require high-density connectivity for numerous devices.
• Enterprise Deployments: Perfect for enterprises seeking scalable and manageable wireless deployments.
• Mesh Networking: Expands network coverage without needing extensive cabling.​

In the Box

• UniFi AC Mesh Access Point (UAP-AC-M)
• PoE Injector
• Mounting Bracket
• Screws and Wall Anchors
• Quick Start Guide

Technical Overview

The UAP-AC-M is a weather-resistant, high-performance outdoor access point, It utilizes 2×2 MIMO technology to deliver fast and reliable Wi-Fi coverage. Dual-band functionality offers optimum performance for a vast range of devices. Weather-resistant design allows it to be mounted in a wide range of environmental conditions.
