Ubiquiti Networks U6-LR UniFi 6 AX3000 Long-Range Access Point

Key Specifications

Wireless Standard: Wi-Fi 6 (802.11ax)

Frequency Bands: Dual-Band (2.4 GHz & 5 GHz)

Maximum Throughput:

• 5 GHz: Up to 2400 Mbps
• 2.4 GHz: Up to 600 Mbps

Total Aggregate Throughput: Up to 3000 Mbps

Radio Configuration:

• 5 GHz: 4×4 MU-MIMO & OFDMA
• 2.4 GHz: 4×4 MIMO
• Antenna Gain:
• 5 GHz: 5.5 dBi
• 2.4 GHz: 4 dBi

Transmit Power: 26 dBm

Processor: 1.3 GHz Dual-Core

PoE Support: 802.3at PoE+ (PoE injector not included)

Mounting Options: Ceiling and Wall Mount

Dimensions: Ø220 x 48 mm (Ø8.7 x 1.9″)

Weight: 800 g (mount not included)

IP Rating: IP54 (Indoor and Semi-Outdoor Use)

Bluetooth: Bluetooth Low Energy (BLE) for location services

Management: Managed by UniFi Network Application (version 6.0.34 or later)​

Key Features

• Wi-Fi 6 Technology: Offers faster speeds, greater capacity, and improved efficiency for high-density deployments.
• Extended Coverage: Designed for long-range deployment, offering robust connectivity over greater distances.
• High Client Density Support: Supports over 300 concurrent clients, ideal for enterprise environments.
• Advanced Radio Management: Offers 802.11k, 802.11r, and 802.11v for high-performance roaming and mobility.
• Easy Integration: Integrates seamlessly with current UniFi networks, offering centralized management and monitoring.​

Use Cases

• Enterprise Offices: Provide stable and quick Wi-Fi connectivity to employees and visitors.
• Retail Spaces: Enhance customer satisfaction through fast and dependable Wi-Fi service.
• Warehouses & Logistics: Ensure seamless, round-the-clock connectivity for efficient operations.
• Public Venues: Offer dependable Wi-Fi coverage in large, open spaces.

Technical Knowledge

The U6-LR makes use of optimized Wi-Fi 6 features such as MU-MIMO and OFDMA to service a large number of devices with high efficiency. The 4×4 MIMO on the 2.4 GHz and 5 GHz bands gives excellent performance with minimal interference. The IP54 rating allows semi-outdoor installation, and there is room for various mounting conditions.

Size & Weight

• Dimensions: Ø220 x 48 mm (Ø8.7 x 1.9″)
• Weight: 800 g (mount excluded)
