TP-LINK WRLS N300 WALL PLATE AP

The TP-Link Omada EAP115-Wall is a sophisticated, plug-to-wall wireless access point that is specifically designed to provide quality wireless coverage to offices, hotels, and multi-dwelling apartments. With its thin profile, it ensures effortless fitting into existing wall outlets, which not only maximizes functionality but also delivers a very pleasing visual experience.

Key Features:

Wireless Standards: IEEE 802.11n/g/b

Frequency Band: 2.4GHz

Max Wireless Speed: 300Mbps

Ethernet Ports: 2 × 10/100Mbps (1 Uplink + 1 Downlink)

Power Supply: IEEE 802.3af Power over Ethernet (PoE)

Max Power Consumption: 2.8W

Dimensions: 86.8 × 86.8 × 30.2 mm

Antenna: Internal 2 × 1.8dBi Omni-directional

Mounting: Wall Plate Mounting

Security Features: Enterprise-class Wi-Fi security protocols

Guest Authentication: Captive portal support for guest Wi-Fi access

Features:

• Seamless Integration: Compatible to be installed into standard EU-type data wall boxes, ensuring clean and professional-looking installation.
• Centralized Management: Supported by TP-Link’s Omada SDN platform for centralized cloud management and smart monitoring of the network.
• High Client Capacity: Supports over 100 concurrent clients, ideal for high-density deployments.
• Easy Deployment: Power over Ethernet (PoE) capability simplifies installation by reducing the need for additional power cables.
• Elegant Design: Extremely thin profile (11mm) seamlessly fits into today’s interior design.

Use Cases:

• Offices: Provide reliable wireless access per room or cubicle.
• Hotels: Provide guests private and secure Wi-Fi networks per room.
• Multi-Dwelling Units: Offer uniform wireless coverage per apartment or unit.

Technical Knowledge:

The EAP115-Wall operates on the 2.4GHz spectrum and has a provision to deliver 300Mbps wireless speed. The dual Ethernet port functionality allows extensive compatibility with multiple network setups, whereby one port serves as the uplink and the other the downlink. IEEE 802.3af PoE delivers power, eliminating complexity in installation without separate power sources. Its compatibility with the Omada SDN platform is an advantage that will allow administrators to centralize management and monitoring of the network, assuring optimum performance and security.

Size & Weight:

• Dimensions: 86.8 × 86.8 × 30.2 mm
• Weight: Approximately 0.2 kg
