TP-LINK WRLS N 300 AP CEILING

The TP-Link EAP110 is a high-performance, cost-effective wireless access point that can be integrated into business environments with ease. Its thin ceiling-mount design and robust features deliver stable Wi-Fi coverage and centralized management capabilities.​

Key Specifications

Wireless Standards: IEEE 802.11n/g/b

Frequency Band: 2.4 GHz (2.4–2.4835 GHz)

Data Rate:

• 11n: Up to 300 Mbps (dynamic)
• 11g: Up to 54 Mbps (dynamic)
• 11b: Up to 11 Mbps (dynamic)

Antenna Type: Internal 2×3 dBi Omni-directional

Transmission Power: Maximum 20 dBm (CE) / Maximum 26 dBm (FCC)

Coverage Area: Maximum 60 m² (650 ft²)

Client Capacity: 100+ simultaneous clients supported

Mounting Options: Ceiling or wall mount (mounting kit provided)

Power Supply: 24V Passive PoE (PoE adapter provided)

Power Consumption: 2.8 W

Dimensions: 189.5 × 170.5 × 29.7 mm

Weight: Around 0.3 kg​

Features

• Centralized Management: Seamlessly integrated into the Omada SDN platform, offering centralized cloud management via Omada Hardware Controllers (OC200/OC300) or Omada Software Controller.
• Guest Authentication: Captive portal with support for Facebook and SMS authentication choices, enhancing the security and ease of use for guest access.
• Multi-SSID Support: Configurable up to 8 SSIDs, with support for segmentation of the network for different user groups.
• Strong Security: Offers enterprise-level security features like WPA/WPA2-Enterprise, 802.1X support, MAC address filtering, and rogue AP detection.
• Quality of Service (QoS): Prioritizes data, voice, and video applications to give the best possible performance for mission-critical traffic.
• Flexible Deployment: Offers managed and standalone AP modes, which provide flexibility for various network implementations.

Technical Knowledge

• PoE Support: Passive PoE support by the EAP110 allows easier installation as it reduces the use of single power cables.
• Environmental Stability: Designed to operate at temperatures between 0°C and 40°C and humidity between 10% and 90% (non-condensing), which is extremely tolerant for different indoor environments.
• Compliance: CE, FCC, and RoHS certified, ensuring compliance with international safety and environmental regulations.​

Package Contents

• TP-Link EAP110 Wireless N Ceiling Mount Access Point
• 24V Passive PoE Adapter
• Power Cord
• Mounting Kit
• Resource CD
• Installation Guide
