TP-LINK Omada 24-Port Gigabit Stackable L3 Managed PoE+ Switch with 4 10G Slots

The TP‑Link Omada SG6428XHP is a powerful, business‑grade network switch designed to bring fast, reliable and flexible networking to offices, buildings, or multi‑device environments. From 24 gigabit PoE+ ports, high‑speed uplinks to Layer‑3 routing, and robust management features, you can combine all rack‑mountable chassis. So need to stress about deploying Wi‑Fi access points, powering IP cameras, or building a scalable network backbone, this switch does it with ease — no complexity required.

Key Specifications

• Ports 24 × 10/100/1000 Mbps RJ45 PoE+ ports
• Uplink / SFP Slots 4 × 10 Gbps SFP+ slots
• PoE Standard IEEE 802.3at/af (PoE+)
• PoE+ Power Budget Up to 720 W total (up to 30 W per RJ45 port)
• Switching Capacity 128 Gbps per unit
• Packet Forwarding Rate 95.2 Mpps
• MAC Address Table 32 K entries
• Jumbo Frame Support Up to 9 KB
• Management Options Web GUI, CLI, SNMP (v1/v2c/v3), RMON, cloud (via Omada SDN), etc.
• Layer‑3 Routing & Protocols Static Routing, RIP, OSPF, ECMP, VRRP, DHCP Server/Relay, multicast routing (PIM‑DM/SM)
• Security & Protection ACL (IPv4 & IPv6), 802.1X authentication, port security, DoS defense, DHCP snooping / ARP inspection, etc.
• Redundancy & Reliability Supports redundant, field‑replaceable hot‑swappable power supplies; physical stacking for redundancy/performance; ERPS & VRRP for highly available network architecture
• Physical Size / Mounting Rack‑mountable; Dimensions approx. 440 × 420 × 44 mm (17.3 × 16.5 × 1.7 in)

Key Features & Benefits

• Gigabit + 10G Speed with PoE+
• Power & Data in One Cable
• Robust Layer‑3 Routing
• Enterprise‑Grade Security & Control
• Centralized & Flexible Management
• High-Availability & Scalability
• Future‑Ready Networking Backbone

Where You Can Use It

• Small-to-Medium Business Offices — Connect all in one network.
  1. Computers
  2. VoIP phones
  3. WiFi access points
  4. Printers
  5. IP cameras
• Hotels, Guesthouses & Hospitality Environments —
  1. Ideal for powering and connecting WiFi APs
  2. Surveillance cameras
  3. Access control devices — with centralized management and guest-network capability.
• Retail Stores / Shops / Outlets — Manage security cameras, POS machines, WiFi for customers, VoIP phones — simple installation thanks to PoE.
• Schools, Campuses & Educational Institutes — Manage computer labs, WiFi zones, IP cameras, VoIP systems across multiple buildings — with centralized routing and VLAN support.
• Multi‑Office or Multi‑Branch Deployments / Branch‑to‑Branch Networks — Use L3 routing + 10G uplinks for backbone networking and branch interconnectivity.
• Data Centers / Server Rooms / Core Network Switch — As a core or aggregation switch: high throughput, 10G uplinks, robust routing, and enough power for connected devices.

Why This Switch Is a Smart Buy

If you need a switch that does more than just connect devices — one that gives you power + data, high speed, flexible routing, strong security, easy management, and growth potential — SG6428XHP delivers. You don’t have to deal with separate power adapters or manage devices one‑by‑one. Everything is centralized, scalable, and future‑proof. For a growing office, a building, a campus, or any network that demands performance + reliability, this switch becomes the backbone your network can trust.
