TP-LINK LiteWave 8-Port Gigabit Desktop Switch with RJ45 PORTS

The TP‑LINK LiteWave TL‑LS1008G is an unmanaged 8‑port Gigabit Ethernet desktop switch. It’s an ideal device for home, small office, surveillance, and dorm deployments. It’s ultra‑quiet, energy‑efficient, and plug‑and‑play—just power it up, plug in your devices, and enjoy rock‑solid gigabit networking with no configuration.

Key Specifications

Brand & Model: TP‑LINK LiteWave TL‑LS1008G
Ports: 8 × 10/100/1000 Mbps RJ45, Auto‑Negotiation & Auto‑MDI/MDIX
Switching Capacity: 16 Gbps
Forwarding Rate: 11.9 Mpps
MAC Address Table: 4K entries
Packet Buffer Memory: 1.5 Mb
Jumbo Frames: Up to 16 KB
Power Input: External adapter: 9 VDC / 0.6 A
Max Power Consumption: ~3.9 W, Heat Dissipation ~13.3 BTU/h
Dimensions (W×D×H): 5.0 × 2.6 × 0.9 in (127 × 66.5 × 23 mm)
Weight: ~3.9 oz (≈ 110 g)
Certifications: CE, FCC, RoHS compliant
Operating Environment: 0–40 °C, 10–90% RH non‑condensing; storage −40 °C to 60°C, 5–90% RH

Feature Highlights

• True Gigabit Speeds: All 8 ports provide 10/100/1000 Mbps, making easy, high-speed transfer of large data and video files, and streaming content without delay.
• Energy‑Smart Green Technology: Adapts automatically, coupling power consumption to connect condition and cable length to reduce carbon footprint and energy bills.
• Quiet & Reliable: Fanless design means silent running—ideal for office environments or domestic entertainment areas.
• Effortless Setup: Totally unmanaged and ready to use immediately—no software, no installation. Plug and play.
• Built‑in Flow Control: IEEE 802.3X compliant and back-pressure capabilities to deliver strong, loss‑free data transmission.
• Flexible Placement: Slick desktop form factor or wall mount—installs seamlessly anywhere.

Typical Uses

• Providing wired network connectivity to PCs, printers, game consoles, IP cameras, and IPTV boxes
• Ideal solution for home offices, study rooms, or student dorms
• Ideal for small business rollouts requiring reliable LAN connectivity
• Enabling surveillance systems, small workgroups, or any gigabit-enabled local area network

Technical Insight

The TL‑LS1008G is a Layer‑2 store‑and‑forward unmanaged switch. It accepts, buffers, and inspects all frames to forward—offering consistent performance even during excessive network traffic. It can manage severe traffic surges because of its 4K MAC address table and 1.5 MB packet buffer. It delivers smoother throughput for high-bandwidth applications like file transfers and backups by supporting jumbo frames up to 16 KB.
