TP-LINK Indoor 54Mbps High Pow

Planning to get ultra-long-range Wi-Fi in or out of your office or home? Look no further! TP-LINK TL-WA5110G offers high, stable 802.11g coverage. Its perfect for wireless ISPs, repeater use, or bridging networks between buildings.

Key Specifications

• Wireless Standards: IEEE 802.11g (54 Mbps), 802.11b (11 Mbps)
• Max Speed: Up to 54 Mbps (802.11g), up to 11 Mbps (802.11b)
• Frequency: 2.4 GHz – 2.4835 GHz
• Ethernet: One 10/100 Mbps RJ45 LAN port, supports Passive PoE
• Antenna: One removable 4 dBi omni-directional (RP-SMA connector)
• Transmission Power:

1. <20 dBm (EIRP) for CE regions
2. <27 dBm (EIRP) for FCC areas

• Reception Sensitivity:

1. −68 dBm @10% PER (54 Mbps)
2. −85 dBm @8% PER (11 Mbps)
3. −88 dBm @10% PER (6 Mbps)
4. −90 dBm @8% PER (1 Mbps)

• Operation Modes: AP, Client (WISP), Repeater (WDS), AP Router, Bridge (point‑to‑point/multipoint)
• Security: WEP (64/128/152‑bit), WPA/WPA2 (TKIP/AES), WPA‑PSK/WPA2‑PSK, MAC filtering, Client Isolation
• QoS & Management: WMM, SNMP, Speed Test, Ping Watchdog, Throughput Monitor
• Physical Dimensions: 165 × 108 × 28 mm (6.5 × 4.2 × 1.1 in)
• Power Supply: 12 VDC / 1 A adapter; passive PoE supported
• Environment:

1. 0 °C–40 °C operating
2. −40 °C–70 °C storage
3. 10–90% operating relative humidity; 5–90% storage relative humidity (non-condensing)

• Certifications: FCC & RoHS compliant

Feature Highlights

• High‑Power Design doubles output and sensitivity up to 50 km (31 miles) in point‑to‑point links in ideal conditions
• Passive PoE Support allows flexible installation—even if there is no convenient power outlet nearby
• Multi‑Mode Operation: Operates as AP, WISP client, router, repeater, or wireless bridge—ideal for small business offices or WISP installs
• Integrated Utilities: Throughput Monitor and Speed Test enable testing in real-time without having to install third-party software
• Ping Watchdog will automatically reboot the device when a specified target is no longer reachable—ensuring uptime and self-healing
• Client Isolation & WDS help safeguard each client and offer wireless coverage extension with a lower degree of interference

Optimal Applications

• Long‑range wireless links between a campus or buildings via 802.11g extended power
• WISP deployments where this appliance is used as a CPE (customer premises equipment) or a repeater
• Wireless LAN to wired bridging at remote locations
• Wi-Fi extension in challenging indoor/outdoor SOHO environments
• Sensitive use cases where self-healing through Ping Watchdog is critical

Technical Insight

This unit utilizes high transmit power along with sensitive receivers to maximize 802.11g wireless range—far beyond standard indoor APs. The TL-WA5110G is designed for performance and flexibility with its multi-mode capability, extensible PoE, and removable high-gain antenna. Even in distant or unsupervised applications, you can effortlessly monitor, test, and troubleshoot connectivity thanks to built-in diagnostic and recovery functionality.

Quick Specs Summary

• Wireless Speed: Up to 54 Mbps (802.11g)
• Frequency Band: 2.4 GHz
• LAN Port: 1× 10/100 Mbps RJ-45 (Passive PoE)
• Antenna: Detachable 4 dBi omni (RP‑SMA)
• Range: Up to ~50 km out (optimal case)
• Power: 12 VDC/1 A adapter; Passive PoE supported
• Modes: AP, WISP Client/Router, Repeater, Bridge
• Security: WEP, WPA/WPA2, TKIP/AES, MAC filter
• Management Tools : SNMP, Speed Test, Throughput Monitor, Watchdog
• Dimensions: 165 × 108 × 28 mm
• Certifications: FCC, RoHS
