Searching for something that expands your wired network? TP-Link LS109P is a compact desktop (or wall-mountable) network switch. It offers power over Ethernet (PoE+) to connected devices.
Since it comes with 8 PoE-enabled ports plus 1 extra Ethernet port, you can easily connect devices like IP cameras, access points, or VoIP phones. Just plug and say goodbye to any configuration.
Key Specifications
- Ports 9 × 10/100 Mbps RJ45 ports (8 of them support PoE+)
- PoE Standard IEEE 802.3af / 802.3at PoE+
- PoE Output (per port) Up to 30 W per PoE port
- Total PoE Power Budget 63 W for all PoE ports combined
- Auto Functions: Auto-Negotiation, Auto MDI/MDIX
- Switching Capacity 1.8 Gbps
- Packet Forwarding Rate ~1.3392 Mpps
- MAC Address Table Size 2,000 entries
- Jumbo Frame Support Up to 1.5 KB
- Power Supply External power adapter (output: 53.5 V DC / 1.31 A)
- Dimensions 171 × 98 × 27 mm (≈ 6.7 × 3.9 × 1.1 in)
- Design / Mounting: Desktop or wall-mountable; durable metal casing
- Operation Mode Unmanaged, plug-and-play, store-and-forward switching
- Special Mode:s Extend Mode (PoE + data up to 250 m), Isolation Mode (traffic separation), PoE Auto Recovery
- Operation Environment 0–40 °C, humidity 10–90% non-condensing
Main Features & Benefits
- 8-Port PoE+ delivering power + data
- Total 63 W PoE budget & up to 30 W per port
- Extend Mode – longer reach (up to 250 m)
- Isolation Mode & PoE Auto Recovery
- Plug-and-play, fanless & silent
- Compact desktop or wall-mount design with sturdy metal casing
- Reliable basic network expansion
Where & How You Can Use It
- Home or small‐office networks
- Surveillance / CCTV systems
- Wireless access point deployments
- VoIP phone networks
- Small retail/shop / POS setups
- Environments needing quiet operation
Why Customers Should Consider This Switch
If you want a simple, cost-effective way to power and connect multiple devices (like cameras, access points, phones) without messy extra power supplies, the LS109P makes it clean and easy. It saves you time and money, reduces clutter, and gives you flexible installation (desktop or wall), silent operation, and reliable network performance.
It’s especially useful if you’re building a small to mid-size network for surveillance, Wi-Fi extension, small business or home office, and you want plug-and-play convenience + PoE power in a compact, durable device.
