Looking for a compact yet powerful switch to expand your network — and power devices over Ethernet too? The TP‑Link TL-SF1006P delivers easy plug‑and‑play networking plus four PoE+ ports so you can connect and power cameras, access points, IP phones, and more — all from one small device.
Key Specifications
- Ports: 6 × 10/100 Mbps RJ45 ports (Ports 1–4 support PoE+)
- PoE Standard: Compliant with IEEE 802.3af / 802.3at
- PoE Power: Up to 30 W per PoE port, total 67 W PoE budget for all four PoE ports together
- Transmission Distance (Extend Mode): Up to 250 m (with PoE + data over a single Ethernet cable)
- Switching Capacity: 1.2 Gbps
- Forwarding Rate: 0.8928 Mpps
- MAC Address Table: 2K entries
- Jumbo Frame Support: Up to 2 KB
- Dimensions: 158 × 101 × 25 mm (approx. 6.2 × 4.0 × 1.0 inch)
- Power Consumption: ~1.9 W (no PoE devices connected); ~74 W when delivering full 67 W to PoE devices
- Design: Fanless, metal casing — compact desktop or wall‑mountable form‑factor
Key Features & What They Mean for You
- 4 PoE+ ports with built-in power supply
- Plug & Play – no configuration required
- Extend Mode (up to 250 m)
- Priority Mode for Ports 1–2
- Compact, sturdy & fanless
Where You Can Use It
- IP Surveillance Systems
- Wireless Access Point (WAP) Deployment
- VoIP Phones / IP Phones
- Small Offices / Home Offices / Dorms
- Small Business Networking
Why You Need This Product
TL‑SF1006P helps in expanding your network throughout a small to medium-sized building. Whether you’re involving multiple devices like IP cameras, Wi‑Fi access points, or VoIP phones, this device provides you with a clean and cost‑effective solution. It even delivers both data and power over a single cable (PoE), so you don’t require individual power sockets and adapters for each device.
It reduces clutter, simplifies installation, and helps you manage network and power in one device. The “plug & play” setup means you don’t need networking expertise — just connect and go. With its robust build, reliable PoE power budget, and support for extended range, it’s ideal for homes, offices, and small businesses that want a dependable, space‑saving network switch without complexity.
