TP-LINK 5-PORT SWITCH 10/100 WITH 4-PORT POE 58W

Need a simple but powerful switch that gives you both data connectivity and power over Ethernet (PoE)? The TL‑SF1005P makes it easy — just plug and play, and you can power and connect devices like IP cameras, Wi‑Fi access points, and VoIP phones — all using a single cable per device.

Key Specifications

• Ports: 5 × 10/100 Mbps RJ45 ports (Ports 1–4 support PoE+)
• PoE Standard: IEEE 802.3af / IEEE 802.3at compliant
• PoE Power Output: Up to 30 W per PoE port, total PoE power budget 67 W for all four PoE ports
• Extend Mode: Up to 250 m data + power transmission (with PoE) — useful for long‑distance runs.
• Switching Capacity: 1 Gbps (enough for typical small office/home usage)
• Forwarding Rate: 0.744 Mpps
• MAC Address Table: 2 K entries
• Jumbo Frame Support: Up to 2 KB
• Design: Fanless desktop / wall‑mountable metal casing for silent, stable operation.
• Dimensions: 99.8 × 98 × 25 mm (approx. 3.9 × 3.9 × 1.0 in)
• Power Consumption: ~ 3.44 W (no PoE devices connected), ~ 74.5 W (with full PoE load)
• Certifications: FCC, CE, RoHS compliant

Key Features & What They Mean for You

• 4‑Port PoE+ with built‑in power supply
• Plug & Play – no configuration required
• Extend Mode up to 250 m
• Priority Mode (Ports 1–2)
• Fanless & compact metal design
• Automatic MDI/MDIX & auto‑negotiation

Where You Can Use It

• IP Surveillance Systems
• Wireless Access Point Deployment
• VoIP / IP Phones
• Small Offices, Shops, or Home Offices
• Dormitories, Guest Houses, Warehouses

Why You (Customer) Need This

TL‑SF1005P can be used for both building and expanding a small-to-medium network. It supports PoE (IP cameras, Wi‑Fi access points, VoIP phones, etc.) and all other devices. No more cable clutter; it also removes the need for separate power adapters. You can also run both data and power through a single Ethernet cable. Furthermore, it’s a cost‑effective and reliable choice for the home, so you get a stable PoE budget, an extended module, along with a plug-and-play design.
