Teltonika – PoE+ L2 managed Switch 8 10/100/1000, 2 SFP ports

The Teltonika TSW202 Industrial Managed PoE+ Switch is a highly reliable and efficient Layer 2 managed Ethernet switch that comes equipped with robust networking features and Power over Ethernet (PoE+) support on all 8 Gigabit Ethernet ports and 2 SFP fiber uplink ports. The device has been designed to suit the working of various industries and features support for protocols such as PROFINET, EtherNet/IP, and MRP. This device is highly beneficial for various industries that require power and speed.

Key Features & Benefits

• 8 × Gigabit PoE+ Ports: These RJ45 ports provide transmission speeds of up to 10/100/1000 Mbps with IEEE 802.3af/at PoE+ power on each port, which has a power supply of up to 30 W.
• 2 x SFP Fiber Uplink Ports: Enables long-distance high-speed fiber connectivity and is suited for applications involving data backbone and network expansion.
• Managed L2 with L3 Features: This offers complete Layer 2 switching with features such as VLAN, STP/RSTP, QoS, DHCP services, and extra static routing functionalities.
• Industrial Protocol Support: Compatible with PROFINET (Class B), EtherNet/IP, and MRP.
• Teltonika’s TSWOS: Intuitive switch operating system that facilitates versatile configuration, monitoring, and management.
• Powerful Power Budget: With an overall PoE power output of 240W, you can power multiple high-power devices from a single switch.
• Robust and Compact Design: Comes with an aluminium housing that has a built-in DIN rail bracket.

Key Specifications

• Brand Teltonika Networks
• Product Name: TSW202 Industrial Managed PoE+ Switch
• Model / SKU TEL‑TSW202000000
• Switch Type Managed Layer 2 Ethernet Switch
• Ports 8 × RJ45 Gigabit (10/100/1000 Mbps)
• PoE+ Support IEEE 802.3af/at (all 8 ports)
• PoE Power per Port Up to 30 W
• Total PoE Budget ~240 W
• Fiber Uplinks 2 × SFP ports
• Switch Bandwidth 20 Gbps (non‑blocking)
• MAC Address Table 8 K entries
• Packet Buffer 512 KB
• Static Routing Yes (IPv4/IPv6)
• Power Input 7 – 57 VDC
• Operating Temp –40 °C to +75 °C
• Housing Anodised aluminium
• Dimensions (W×H×D) 132 × 44.2 × 122.2 mm
• Weight ~610 g
• Mounting DIN‑rail, wall, flat (kit needed)

What This Switch Can Do

• Fast Gigabit Network: Gigabit speed is offered on all ports to ensure a fast data stream and connectivity within your network.
• PoE Power: With PoE Power, devices such as an IP Camera, a Wireless Access Point, a VoIP Phone, and sensors can be powered via an Ethernet cable without any power adapter.
• Fiber Uplink Ready: Two SFP sockets enable you to establish fiber optic connectivity for long-distance communications.
• Managed Network Control: The addition of VLANs, Quality of Service, port configurations, and industrial protocol support makes the TSW202 device capable of organizing, prioritizing, and controlling traffic.
• Industrial-Grade Build Features: Made with expectations of reliability even at adverse temperatures, an ideal choice for an automation environment.

Where You Can Use It:

This switch is ideal for:

✔ Smart buildings and enterprise LANs – Centralized PoE power for cameras and Wi-Fi APs
✔ Industrial Networks & Automation – support for PROFINET and EtherNet/IP with fiber backbone.
✔ Transportation and Surveillance Hubs – Network and Power Multiple PoE Devices Throughout a Long Distance
✔  IoT deployments – power and manage sensors and edge devices with one managed platform
✔ Office & Campus networking – Flexible VLANs and QoS functionality enhance network segmentation

Why Customers Need This Product

Customers prefer the Teltonika TSW202 because it offers a combination of network strength, control, and flexibility within a single module:

✔ All-in-one device for Power and Data – it lowers cabling and installation complexity
✔ Centralized Network Management – organize traffic, protect your network, and have control over all network-related services.
✔ Supports industrial protocols — best for automation and intelligent systems
✔ Robust in demanding environments – designed to last and resist temperature extremes
✔ Scalable & future-ready – Fiber uplinks and managed elements scale to meet your evolving network needs

The TSW202 is more than just another switch; it’s an intelligent PoE control center designed for professional networks that require performance and flexibility
