RUIJIE RG-RAP2260(E) Reyee Wi-Fi 6 3202Mbps Multi-G Ceiling Access Point

RUIJIE Reyee RG-RAP2260(E) is a high-performance Wi-Fi 6 ceiling access point, which supports super-fast wireless data transfer at a speed of up to 3202 Mbps. It also supports Multi-G Ethernet Uplink. This ceiling mount access point is designed to tackle the latest network requirements. It is a ceiling-mounted access point that improves Wi-Fi capacity and provides support for heavy Wi-Fi use.

Key Specifications

Wireless & Performance

• Wi‑Fi Standard: Dual‑band 802.11ax (Wi‑Fi 6) for faster, more efficient wireless connections
• Maximum Wireless Rate: 3201 Mbps combined (800 Mbps @ 2.4 GHz + 2401 Mbps @ 5 GHz)
• Radio Design: Dual‑radio 4×4 MIMO on both 2.4 GHz and 5 GHz bands
• Antennas: Built‑in omnidirectional antennas on both bands

Ports & Connectivity

• Ethernet Ports:
  • 1× 10/100/1000BASE‑T port
  • 1× 10/100/1000/2500 BASE‑T Multi‑G uplink port for 2.5 Gbps wired speed
• Power Options: Supports PoE+ (802.3at) and DC 12 V power adapter
• Max Power Consumption: 25.4 W

Physical & Environmental

• Dimensions: 220 × 220 × 35 mm (8.66 × 8.66 × 1.38 in)
• Weight: ≤ 0.55 kg (1.21 lbs) (device only)
• Mounting: Ceiling or wall installation
• IP Rating: IP41 (indoor protection against dust and light moisture)
• Operating Temp: 0 °C to 40 °C (32 °F to 104 °F)

Key Features & Benefits

• Ultra Fast Wi-Fi 6 Performance – Supports combined wireless speeds of up to 3202 Mbps.
• Multi-G Uplink (2.5GbE) – An advanced wired connectivity solution that enhances backhaul speed and prevents congestion in a saturated network.
• 4×4 MIMO Technology — Enhances signal strength with support for a large number of devices.
• Many Devices Supported – Optimized for many clients, which makes it suitable for high-density areas.
• Easy Cloud & Mesh Setup – Supported by Ruijie Cloud App and Self-Organizing Network (SON) technology.
• Flexible Installation — Mount on the ceiling or wall, suitable for different installation requirements.
• Faithful Indoor Solution – The white slim design never calls attention to itself in any way.

Where This Access Point Is Best Used

This access-point is best-suited for:

✔ Offices & Meeting Rooms — Fast and stable wireless connectivity for employees, technology, and collaboration tools.
✔ Schools & Universities – Wi-Fi coverage in classrooms, laboratories, and student areas.
✔ Hotels & Hospitality — High-capacity guest Wi-Fi in lobbies, rooms, and public areas.
✔ Retail Stores & Cafés — Excellent wireless networking support for retail point-of-sale systems and customer-operated devices.
✔ Homes & Smart Buildings – Suitable for huge homes that contain many smart devices and applications that involve heavy video streaming.
✔ Public Spaces – Event halls, libraries, or reception areas where a large number of users access at the same time.

Why Customers Need This Product

A reliable Wi-Fi network has become a necessity, not a luxury. The RUIJIE Reyee RG-RAP2260(E) offers next-generation Wi-Fi 6 performance, fast wired network data transfer, and cloud-based network management. Such features make it the best suited for a network where there are multiple users. This access point brings you:

✔ Fast-speed Wi-Fi for work, play, and streaming
✔ Improved network capacity for dozens of devices
✔ Future-proof wired connectivity featuring Multi-G uplink support
✔ Easy setup and remote management for busy admins. No matter what the situation

Whether you are upgrading your business Wi-Fi or adding new wireless range – this ceiling mount access point will provide you with speed, reliability, and ease of use all in a single package.
