RUIJIE 24-Port SFP L2 Managed 10G Switch, 24 SFP Slots, 8 Gigabit RJ45 Combo Ports, 4 *10G SFP+ Slots, 19-inch Rack-mountable Steel Case

The Ruijie Reyee RG-NBS3200-24SFP-8GT4XS is a high-performance Layer 2+ managed network switch designed specifically for business use. Some features include: 24 fiber ports through SFP connections, 8 combo Gigabit RJ45 ports, as well as four 10G SFP+ uplink slots, making it ideal for businesses with high fiber connectivity needs, data transmission, as well as cloud management.

Key Specifications

General

• Product: Ruijie Reyee RG‑NBS3200‑24SFP‑8GT4XS
• Type -Layer 2+ Managed Switch
• Warranty: 5 years

Ports & Connectivity

• 24 x 1 Gbps SFP Fiber Ports (uplinks or fiber access)
• 8 x Combo RJ45 Ports (10/100/1000BASE-T + S
• 4 x 10 G SFP+ uplink ports for fast backbone connectivity
• No RJ45 non-combo copper ports

Performance

• Switching Capacity: 128
• Forwarding Rate: ~96
• Jumbo Frame Support: up to 9216 bytes

Cloud & Software

• RuiJie Cloud Management – remote monitoring & configuration at any time
• VLAN Support, Link Aggregation, IGMP Snooping
• Security Policies — port isolation, broadcast storm controls

Reliability & Environment

• MTBF: ≈400,000 hours
• Operating Temperature: 0 °C to 50 °C
• Surge Protection: ±6 kV on service ports & power connector

Physical

• 19″ rack-mounted steel housing (standard rack mount)
• An industrial construct meant for continuous processing

Top Feature & Benefits

✔ High-speed fiber networking
The availability of 24 SFP ports and 4 × 10G SFP+ uplinks enables you to set up high-performance fiber backbone networks that are ideal for data center and campus backbone environments.

✔ Flexible Combo Ports
The 8 combo RJ45/SFP ports offer you flexibility to use them as copper or fiber ports as needed, keeping your network flexible and economical.

✔ Cloud Management
All of this can be controlled from anywhere using the Ruijie Cloud management system to be able to check statistics and make VLAN changes.

✔ Enterprise-Grade Performance
Designed to operate in business environments that involve strong switching capabilities, link aggregation, and support for VLAN and IGMP Snooping to handle traffic effectively.

✔ Strong Network Protection
The broadcast storm control and port isolation features ensure that your network is shielded against various problems that may endanger your data.

Where This Switch Can Be Used

This switch is perfect for:

• Campus & Enterprise Networks – core or distribution layer for fiber-centric architectures
• Data Centers & Server Rooms – High-speed uplinks & fiber aggregation
• Security & CCTV Backbones – connect many cameras via fiber cables
• Large Offices & Commercial Buildings – Seamless Multi-Site Connectivity
• Carrier/ISP Edge Networks – Flexible fiber port density for service connections

Why Customers Need This Product

• Future-Ready Network BackBONE – Built for today’s fiber applications and tomorrow’s data.
• Easy to Manage – This is because cloud solutions reduce IT work, as well as the time involved in solving issues.
• Flexible Port Options – SFP+ combo models support the combination of fiber & copper.
• Reliable & Secure – Enterprise features with enhanced security & reliability.

If you are developing a professional fiber backbone network or high-density network that demands flexibility, remote management, and superior performance, then Ruijie Reyee RG-NBS3200-24SFP-8GT4XS is a great pick.
