RUIJIE 24-Port L2 Managed POE 10G Switch, 24Gigabit RJ45 POE/POE+ Ports, 4 *10G SFP+ Slots, 370w PoE Power Budget, 19-inch Rack-Mountable Steel Case

Ruijie Reyee RG-NBS3200-24GT4XS-P is an advanced Layer 2+ managed PoE switch that has been specifically designed for future-proofed business networks, modern surveillance networks, and enterprise networks. This reliable network switch features 24 Gigabit PoE+/PoE RJ45 interfaces and 4×10G SFP+ uplink interfaces along with cloud-level management capabilities.

Key Specifications

General

• Brand & Model: Ruijie Reyee RG-NBS
• Switch Type: Layer 2 + Managed PoE Switch
• Warranty: 5 years

Ports and Connectivity

• 24 × 10/100/1000BASE-T RJ45 PoE/Po
• 4 × 10-Gb SFP+ uplink ports (fiber/D
• Lack of combo or standard SFP ports

PoE Power

• Overall PoE Budget: 370 W
• Max Per-Port PoE Output Power: Up to 30 W (IEEE 802.3at Type

Performance

• Switching Capacity: 128 Gbps
• Forwarding Rate: ~96 Mpps
• MTU/Jumbo Frame Support: up to 9216 bytes

Security & Reliability

• PoE Watchdog (allows devices to be powered and stable)
• Port Isolation for a Secure Segmented Network
• Broadcast Storm Control for Preventing Traffic Overload
• Surge Protection: ±6 kV for service ports and power connectors
• Operating Temperature: 0°C +50°C
• MTBF: Approximately 400

Management & Software

• Ruijie Cloud Management: monitor, configure, and maintain remotely
• Zero-Touch Provisioning (SON) for fast, effortless deployment
• Layer 2 Features: VLANs, Link Aggregation, IGMP Snooping

Physical

• 19-inch rack-mountable steel case – The standard rackable format for server racks.
• Note: Detailed specs & weight measurements can also be incorporated if required, which are in ~440x357x44mm range (third-party sources).

Top Features & Benefits

• Full PoE+ Support
  Provide network connectivity and power for devices such as IP cameras, wireless access points, VoIP phones, access control panels, and many others – in just one cable. With a generous 370 W budget, it can support dense PoE environments.
• Blazing 10G U
  Four 10-Gigabit SFP+ uplink ports provide high-speed uplink connections to servers or other high-end switches. This feature was ideal for the data center.
• Cloud-Based Management
  Connect to your network from anywhere with Ruijie Cloud Management, so you can easily view traffic conditions, modify configurations, and troubleshoot problems without having to be at the site.
• Enterprise-Grade Stability
  Features such as PoE Watchdog, port isolation, and surge protection ensure your network stays running and protected, even under peak or unexpected circumstances.
• Great for CCTV & Security Networks
  The ability to see and process IP camera traffic is very useful in CCTV technology and helps to provide a stable stream of video data.

Where You Can Use This Switch

The following are just a few examples of where this switching device can be effectively utilized in a networking scenario:

• Office & Enterprise Networks – connect workstations, servers, and Wi-Fi APs.
• CCTV & Surveillance Systems – power and connect multiple security cameras.
• Hotels & Hospitality – manage guest networks, VoIP, and security devices.
• Retail & Shops – POS devices, sensors, cameras, and employee devices.
• Schools & Campuses – manage computer class networks, administration systems, and WI-FI.
• Factory & Industrial Networks – reliable connectivity for IoT devices and monitoring.

Why Customers Need This Product

The network switch is not a collection of ports anymore, with the world connected. The Ruijie RG-NBS3200-24GT4XS-P is a network switch that offers you:

• Strong support for PoE – eradicates the need for multiple power adapters.
• High-speed 10G uplinks, ready to support big data and video-intensive applications.
• Cloud management made simple – more uptime, less maintenance.
• Solid reliability & security — professional grade stability.

If you’re constructing or upgrading a business network, say if you need something fast, easy to manage, and powered via PoE, this switch is a great improvement
