LANMUS-2421FUGP non-management Standard 24GE+2GE+1SFP 1000M POE Switch

The LANMUS LM-2421FUGP PoE switch is designed as a high-performance 24-port gigabit Ethernet PoE+ switch that is suitable for use in the networks of today where efficient powering and high-speed data transfer are highly important without the complexity of setup.

The LANMUS switch is designed as an unmanaged PoE switch that makes the process of powering and connecting devices cost-effective and efficient.

Key Specifications

Model: LANMUS LM‑2421FUGP

Ports:
24 × 10/100/1000Base‑T PoE RJ45 ports (Data + Power)
2 × 10/100/1000Base‑T RJ45 uplinks
1 × 1000Base‑X SFP fiber uplink

PoE Power:

Per port: up to 30W
Total power budget: 370W
Network Standards: IEEE802.3 / IEEE802.3u / IEEE802.3X / IEEE802.3ab
Switching Capacity: 54 Gbps
Processing: Store‑and‑Forward
MAC Address Table: 8K entries
Dimensions: 310 × 210 × 44 mm (W×D×H)
Operating Temp: 0°C ~ 55°C
Plug & Play: No configuration needed — ready to use right out of the box

Features that Matter

• High-Speed Gigabit Performance
• Integrated PoE+ Power
• SFP Optical Uplink
• Plug & Play Functionality
• Reliable and Durable

What this Can Be Used For

In this case, this switch is ideal for use in a variety of network topologies:

• CCTV & Surveillance Systems: Power and connect 24 PoE cameras without additional power supplies.”
• Small & Medium Offices: Network & PoE devices such as voice-over-Internet Protocol phones & wireless access points should be centralized.
• Retail or Hospitality Network or Wi-Fi: Enable gigabit speeds with Internet connectivity as well as AP power.
• Smart Buildings & Automation: Use PoE-based sensors, controllers, and Internet of Things devices.
• Network Expansion Projects: Excellent for extending an existing network without restructuring core systems.

Why You Need This Product

If you need a dependable Gigabit network infrastructure that also switches power to your devices via Ethernet, then you can’t go wrong with Lthe ANMUS LM‑2421FUGP PoE switch:

• Cables & power adapters are cheaper because Power-over-Ethernet sends power & data through one cable.
• Plug & play simplicity: the final solution if you’re not a computer network whiz yourself.
• Capable of handling demanding applications — supports smooth video streaming, VoIP, and wireless connectivity.
• Fiber Uplink Ready – Scalable long-distance network expansion.
