HUAWEI S310-48P4S (48*10/100/1000BASE-T ports(380W PoE+), 4*GE SFP ports, built-in AC power)

The Huawei S310-48P4S is a very powerful 48-Gigabit PoE+ managed network switch that is designed to offer blazing-fast and reliable Ethernet network connectivity, and the ability to provide Power over Ethernet (PoE+) capability to the network. With the 4 GE SFP uplink ports and the 380 W PoE power sourcing capability of the switch, the switch is ideal for the connection and powering of a vast number of devices, such as IP cameras, phones, access points, and computers.

This is a professional-level switch designed for use in office environments, small to medium businesses, retail environments, schools, and anywhere a reliable, flexible, and easily managed network infrastructure is required.

Primary Specifications

• Brand & Model Huawei S310-48P4S
• Ports 48 × Gigabit Ethernet (10/100/1000BASE-T) PoE+
• Uplink Ports 4 × GE SFP (1 Gbps)
• PoE Power Budget 380 W total
• Switching Capacity 104 Gbps
• Packet Forwarding Rate 77 Mpps
• Management Managed switch (Layer 2+/Cloud/Web/CLI/SNMP)
• Power Supply Built-in AC (100–240 V)
• Cooling 2 × built-in fans, intelligent speed control
• Dimensions (W×D×H) 442 × 220 × 43.6 mm
• Weight (No Packaging) 3.24 kgOperating Temp. –5 °C to +50 °C
• Mounting Rack/Desk/Wall mountable
• Chassis Metal, 1 U form factor

Key Features

• 48 Gigabit PoE+ Ports:  Allows for a fast EtherNet for a total of 48 devices that can be powered through a single cable that supplies them with power as well.
• High 380 W PoE Power Budget: Enables power sourcing to a combination of 802.3at (PoE+) and 802.3af (PoE) devices, such as IP cameras, wireless AP, VoIP phones, and more.
• 4 GE SFP Uplink Ports: It provides flexible fiber or copper uplink connections to core networks or servers.
• Managed Switch Features: Where you can easily set up VLANs, QoS, Access Control, and other sophisticated network settings through Web, CLI, Cloud, and/or SNMP options, ideal for well-organized and secure business networks.
• High Throughput & Low Latency: With the 104 Gbps switching throughput and 77 Mpps forwarding rate, this switch is capable of handling a heavy volume of data with no latency.
• Rack Mountable 1U Design: The device features a 1U rack mountable design, making installation neat and organized.
• Built-in AC Power Supply: Makes it easier to set up since no power bricks are needed.

Typical Uses

This switch outperforms its competitors in the following ways:

• Enterprise & Office Networks:  Connects desktops, printers, VoIP solutions, as well as Wi-Fi access points in a centrally switched network.
• IP Surveillance Systems: Ideal for powering and networking large numbers of PoE cameras smoothly.
• Wireless Networks: Centralized PoE power and uplinks – ideal for Wi-Fi Access Point wireless backhaul.
• Schools & Campuses: Backs support for segmented VLANs and safe traffic policies for various departments.

Simple Technical Insight

The S310-48P4S from Huawei is a managed PoE+ switch. As a managed switch, it not only transmits network data but also provides features for controlling, securing, and optimizing network data transmission. Its PoE+ interfaces can both transmit data and provide a maximum of 30 W of power via Cat5e/Cat6 cables. GE SFP uplink interfaces enable versatile connections of the switch with wide network infrastructures via fiber or copper SFP modules.

Reasons Why You Require This Product

This switch is ideal for clients who:

• A switch is a single device that can power, connect, and manage up to dozens of devices in a network.
• Easy wiring and cost effectiveness with PoE over the need for dedicated power supplies
• Advanced Networking Control for Performance, Security, and Optimization
• Scalability – develop your network without upgrading very often

Whether it’s for a smart office solution, a secure surveillance network, or a business-level LAN solution, the Huawei S310-48P4S offers performance, functionality, and a high level of reliability.
