D-LINK 48-PORT GIGAABIT MAX POE SWITCH MANAGED

Searching for stackable smart managed switch? Look no further! D-Link DGS-1510-52XMP is an enterprise-grade ideal for today’s business networks. This switch not only delivers scalability and reliability, but also in-depth management functionality. So whether you’re a small and medium enterprises, this switch comes with 48 Gigabit Ethernet ports and Power over Ethernet Plus (PoE+) support, 4 10G SFP+ uplink ports, and Layer 3 features.

Key Specifications

Ports:

• 48 x 10/100/1000BASE-T PoE+ ports
• 4 x 10G SFP+ uplink ports

Switching Capacity: 176 Gbps

Maximum Packet Forwarding Rate: 130.95 Mpps

PoE Budget:

• 370W (no Redundant Power Supply)
• 740W (with optional DPS-700 RPS)

Power Consumption:

Maximum: 486.9W (PoE on)

Standby: 58.8W (PoE off)

MTBF (Mean Time Between Failures): 303,027 hours

Form Factor: 19″ rackmount, 1U height

Cooling: 4 DC fans

Memory:

DRAM: 256MB

Flash: 32MB

CPU Speed: 400 MHz

Operating Temperature: 0°C to 50°C

Relative Humidity: 5% to 95% (non-condensing)

Features

Layer 3 Lite Capabilities: It has Multiple Spanning Tree Protocol (MSTP) and static routing for better traffic management.

10G SFP+ Stacking: This method creates a single network with 288 gigabit ports by physically stacking up to six devices.

Advanced Security:

• D-Link Safeguard Engine to prevent DoS attacks
• IEEE 802.1X port-based authentication
• ARP Spoofing Prevention
• DHCP Server Screening

Traffic Management:

• For the best VoIP and surveillance, use Auto Voice VLAN and Auto Surveillance VLAN (ASV).
• Quality of Service (QoS) for applications that are given priority.

IPv6 Ready: Capable of supporting dual-stack IPv4/IPv6 mode and MLD Snooping, among other IPv6 functionalities.

Energy-Efficient Design:

• D-Link Green 3.0 technology
• IEEE 802.3az Energy Efficient Ethernet support
• Smart fan technology for dynamic cooling

Comprehensive Management:

• Web-based GUI, Command Line Interface (CLI), and SNMP support
• D-View 8 Network Management System for centralized monitoring and configuration

Use Cases

• Enterprise Networks: Ideal for businesses with requirements of high-density PoE+ ports for devices like IP cameras, wireless access points, and VoIP phones.
• Surveillance Systems: Compatible with surveillance cameras with ease using ASV, providing high-quality video transmission.
• VoIP Deployments: In VoIP applications, voice traffic is prioritized to guarantee call quality.
• Data centers: Offer fast 10G uplinks for quick server connectivity and data transfer.
