D-LINK 24-Ports GIGABIT MANAGED POE SWITCH

The D-Link DGS-3130-30PS is a switch that you can put in a rack. It is a gigabit Layer 3 managed PoE switch. This D-Link DGS-3130-30PS switch has 24 PoE Gigabit Ethernet ports. It also has high-speed uplinks for fiber and copper.

The D-Link DGS-3130-30PS switch is really good for businesses, campuses, and big networks. These D-Link DGS-3130-30PS switches give you scalable connectivity. You can use the D-Link DGS-3130-30PS switch to power PoE devices like access points, VoIP phones, and IP cameras. You can power these devices from the D-Link DGS-3130-30PS switch. You do not need to use power supplies for these devices.

Key Specifications

• Model D-Link DGS-3130-30PS
• Ports 24 × 10/100/1000BASE-T PoE ports
• Uplink Ports 2 × 10GBASE-T + 4 × 10G SFP+
• PoE Standard IEEE 802.3af / IEEE 802.3at (PoE+)
• PoE Power Budget 370 W (expandable to 740 W with DPS-700 RPS)
• Switching Capacity 168 Gbps
• Max Forwarding Rate 125 Mpps
• Management Full L2/L3 manageability
• Stacking Support Up to 9 units (80 Gbps stacking bandwidth)
• Surge Protection Built-in 6 kV on all access ports
• Dimensions 440 × 350 × 44 mm
• Weight ~4.66 kg
• Redundancy Dual power support & ERPS <50 ms recovery
• Operating Temp. 0–50 °C
• Storage Temp. −40–70 °C
• Humidity 10–90 % RH operating
• MTBF ~409,054 hours

Main Features & Benefits

• Advanced Managed Switch (Layer 3 Capabilities)
• Power-over-Ethernet (PoE) Support
• High-Speed Connectivity
• Reliable & Secure
• Redundancy & ScalabilityEasy & Flexible Network Management

Where You Can Use This Switch

• Enterprise and Campus Networks.
• Office Environments
• IP Surveillance Systems
• Data Centers and Server Rooms.
• Retail, Hotels, & Schools

Why You Need This Product

Choosing the D-Link DGS-3130-30PS means getting:

✔ Robust enterprise-level performance with Layer 3 routing and advanced traffic control.
✔ Centralized PoE delivery — eliminates extra power adapters and simplifies cabling.
✔ High-speed uplinks for modern data demands like video, VoIP, and cloud apps.
✔ Future-proof scalability with stacking support and flexible expansion.
✔ Network uptime and security backed by surge protection, redundancy, and strong access controls.
