CISCO CBS MANAGED 48-PORT GIGABIT POE SWITCH

Key Specifications

Ports:

• 48 × 10/100/1000 Mbps Gigabit Ethernet PoE+ Ports
• 4 × 1G SFP Uplink Ports

Power over Ethernet (PoE+):

• Total PoE Power Budget: 370W
• IEEE 802.3af/at Compliant

Switching Capacity:

• 104 Gbps

Forwarding Rate:

• 77.38 Mpps

Layer 3 Features:

• Static Routing
• Layer 3 Switching

Management:

• Cisco Business Dashboard
• Web User Interface (UI)
• Command-Line Interface (CLI)

Form Factor:

• Rack-Mountable (1U)

Dimensions:

• 445 mm × 350 mm × 44 mm (17.5 in × 13.78 in × 1.73 in)

Weight:

• Approximately 4.5 kg (9.92 lbs)

Power Supply:

• Internal Power Supply

Operating Temperature:

• 0°C to 40°C (32°F to 104°F)

Certifications:

• CE, UL, RoHS

Key Features

Large PoE+ Power Budget: Provides 48 ports with up to 370W of PoE+ power, which powers devices such as security cameras, wireless access points, and IP phones.

Sophisticated Layer 3 Features: Uses static routing, which enables efficient traffic management across VLANs.

Detailed Security Features: Offers 802.1X port security, DHCP snooping, and IP-MAC binding to secure your network.

Quality of Service (QoS): Prioritizes essential traffic like voice and video to ensure the best performance.

Energy Efficient: Complies with IEEE 802.3az Energy Efficient Ethernet standards to reduce power consumption.

True Stacking Support: Supports up to four switches stacked and controlled as a single device, simplifying network management.

Easy Management: Managed via Cisco Business Dashboard, providing a simple-to-use interface to monitor and set up.

Use Cases

Small to Medium-Sized Businesses (SMBs):

• Ideal for companies seeking an affordable, secure, and scalable network solution.

Unified Communications:

• Transmits voice, video, and data traffic over a single network infrastructure.

Surveillance Systems:

• Powers and connects IP cameras and other equipment.

Wireless Networks:

• Provides PoE+ to wireless access points with seamless connectivity.

Technical Knowledge

Cisco CBS350-48P-4G-UK switch is designed to meet the networking needs of modern businesses. The PoE+ feature facilitates easier deployment of powered devices, with fewer instances of using independent power sources. Layer 3 static routing provides the benefit of optimizing network efficiency, by passing traffic between VLANs without putting additional strain on the core router. Security features that guard against assaults and unwanted access include DHCP snooping and 802.1X authentication. The energy-efficient design of the switch lowers operating expenses without compromising performance and functionality.
