Aruba Instant On 1930 24G 4SFP+ 195W Switch

The Aruba Instant On 1930 24G Class4 PoE 4SFP/SFP+ 195W Switch (JL683B) is a smart-managed Layer 2+ Gigabit Ethernet switch ideal for small and medium enterprises. It has 24 Gigabit Ethernet ports with Class 4 PoE support and 4 SFP/SFP+ ports for high-speed fiber connectivity. The switch provides advanced features, simple management, and robust security, making it ideal for bandwidth-intensive applications.

Key Specifications:

Model Number: JL683B

Ports:

• 24 x RJ-45 autosensing 10/100/1000 Class 4 PoE ports
• 4 x SFP/SFP+ 1G/10G fiber uplink ports

PoE Budget: 195W total

Switching Capacity: 128 Gbps

Throughput: 95.23 Mpps

Management Options: Cloud-hosted web interface, Instant On mobile app, local Web UI

Security Features: IEEE 802.1X, VLANs, ACLs, DoS protection, management access control

Dimensions: 17.42 x 10.42 x 1.73 inches (44.25 x 26.47 x 4.39 cm)

Weight: 7.69 lb (3.49 kg)

Power Consumption: 280W maximum, 30W idle

Warranty: Limited lifetime warranty with 24/7 phone support for 90 days and chat support for the life of the warranty

Features:

• High-Performance Connectivity: Provides 24 Gigabit Ethernet ports with PoE+ support and 4 SFP/SFP+ ports for high-speed fiber connections, providing predictable performance for bandwidth-intensive applications.
• Advanced Management: Includes flexible management features, such as cloud-hosted web interface, Instant On mobile app, and local Web UI, for easy setup and monitoring from anywhere.
• Strong Security: Provides features like IEEE 802.1X, VLANs, ACLs, and DoS protection to safeguard your network against unauthorized access and attacks.
• Energy Efficient: Meets Energy Efficient Ethernet standards, conserving energy without compromising on performance.
• Quiet Operation: Fanless design for noise-free operation, suitable for noise-sensitive environments.

Use Cases:

• Small to Medium-Sized Businesses: Ideal for offices requiring secure and dependable network connectivity for various devices and applications.
• Retail Stores: Facilitates PoE-capable devices like IP cameras and POS terminals, simple to deploy and less costly to cable.
• Hotel Segment: Facilitates seamless connection for guests and staff, support for bandwidth-consuming applications like video streaming and VoIP.
• Schools and Institutions: Facilitates robust network infrastructure for classroom and administrative floors, support for digital learning software and communications equipment.

Technical Expertise

The Aruba Instant On 1930 24G Class4 PoE 4SFP/SFP+ 195W Switch is designed to deliver high-performance networking with feature-rich functionality for growing businesses. Smart-managed functionality offers easy configuration and monitoring, and the PoE+ support allows for easy powered device deployment. SFP/SFP+ ports allow for scalability and flexibility for future network expansion.

Size & Weight

• Dimensions: 17.42 x 10.42 x 1.73 inches (44.25 x 26.47 x 4.39 cm)
• Weight: 7.69 lb (3.49 kg)
