8-PORT 10/100MBPS + 3-PORT GIGABIT DESKTOP SWITCHWITH 8-PORT POE+ PORT:8*10/100MBPS POE+ PORTS,2*GIGABIT NON-POE PORTS,1*GIGABIT SFP SLOTS

The TP-Link TL-SL1311P is an unmanaged desktop switch. It makes network extension easy. It also enhances connectivity for small and medium-sized businesses. With 8 Fast Ethernet (10/100Mbps) ports and 3 Gigabit ports (2 RJ45 and 1 SFP), it offers a stable solution for most networking applications.

Key Specifications:

Ports:

• 8 × 10/100Mbps RJ45 PoE+ Ports
• 2 × Gigabit RJ45 Ports
• 1 × Gigabit SFP Port

Power over Ethernet (PoE):

• Compliant with IEEE 802.3af/at standards
• Delivers a maximum of 30W per port

Total PoE power budget: 65W

Performance:

• Switching Capacity: 7.6 Gbps
• Packet Forwarding Rate: 5.6544 Mpps
• MAC Address Table Size: 2K entries
• Jumbo Frame Support: 16 KB

Power Supply:

• External Power Adapter: 53.5V DC / 1.31A

Physical Dimensions:

• Dimensions (W x D x H): 209 × 126 × 26 mm
• Weight: Approximately 0.5 kg

Features:

• Plug and Play: No configuration required, ideal for rapid deployments.
• PoE+ Support: Delivers power and data in one cable to PoE equipment like IP cameras and access points.
• Isolation Mode: Helps provide one-click client traffic isolation for enhanced security and performance.
• PoE Auto Recovery: Automatically reboots non-responsive PoE-powered devices to ensure uninterrupted operation.
• Fanless Design: Operates silently, suitable for noise-sensitive environments.
• Strong Metal Enclosure: Promotes sustainability and ruggedness across environments.

Applications:

• IP Security Networks: Perfect for connecting IP devices and NVRs in security networks.
• Wireless Access Points: Facilitate the installation of wireless networks by powering access points.
• Networks in Small Offices: Supplement network reach with easy setups sans elaborate configurations.
• Retail Outlet Infrastructure: Promotes network facilities within retail shops to function smoothen.

Technical Insights

TL-SL1311P is an unmanaged switch, i.e., does not require configuration or management using a software utility. It includes Auto MDI/MDIX to automatically identify the type of cable and Auto-Negotiation to negotiate speed as well as duplex mode to optimize. The PoE+ feature complies with IEEE 802.3af/at standards for efficient delivery of power to the devices.
