8 Gigabit electric ports, 2 Gigabit optical ports, 2 USB ports and 1 Console port

The Ruijie RG-S5760C-24SFP/8GT8XS-X is an advanced Layer 3 aggregation switch designed for small and medium campus networks. It offers a comprehensive set of port types, expanded routing capabilities, and robust hardware components to offer efficient and reliable network services.

Key Specifications

Brand: Ruijie

Model: RG-S5760C-24SFP/8GT8XS-X

Fixed Ports:

• 24 × 1GE SFP ports (including 8 combo ports)
• 8 × 1GE/10GE SFP+ uplink ports

Management Ports:

• 1 × Console port
• 1 × USB port (USB 2.0 standard compliant)
• 1 × MGMT port

Switching Capacity: 688 Gbps

MAC Address Table: Up to 32K entries

Power Supply: Dual hot-swappable power modules (1+1 redundancy) support

Cooling: Left-to-right airflow with internal fans

Dimensions: Standard 1U rack-mountable form factor

Features & Benefits

• Flexible Port Configuration: Combines 24 × 1GE SFP ports (with 8 combo ports) and 8 × 1GE/10GE SFP+ uplink ports to match varying network requirements.
• Advanced Layer 3 Routing: Consists of static routing, RIP, OSPF, IS-IS, and BGP to manage network traffic effectively and efficiently as well as provide flexibility when handling traffic.
• Virtual Switch Unit (VSU): Enables multiple switches to be one logical entity, simplifying network management as well as providing greater scalability.
• Robust Security Features: Comprises network security policies, real-time monitoring, Control Plane Protection (CPP), and Network Foundation Protection Policy (NFPP) to ensure network integrity.
• Redundant Power Supply: Dual hot-swappable power modules provide seamless power and system stability.
• Optimized Cooling System: Left-to-right airflow design maximizes heat dissipation to maintain system performance and longevity.

Use Cases

• Campus Networks: Aggregates access switches and provides high-speed uplinks for educational institutions.
• Enterprise Networks: Core or aggregation switch in medium-sized business networks requiring robust Layer 3 functionality.
• Data Centers: Perfect for data center deployments with high-density port layouts and consistent performance.

Package Contents

• 1 × Ruijie RG-S5760C-24SFP/8GT8XS-X Switch
• 1 × Console Cable
• 1 × Power Cord
• 1 × Rack Mount Kit
• 1 × Quick Installation Guide
