24 x 10/100/1000BASE-T ports, 4 x GE/2.5GE/10GE SFP+ ports, PoE power supply, support PoE+, a maximum of 370 W PoE output, and built-in power modulea

Ruijie RG-S5350-24GT4XS-E is a Layer 3 high-performance managed switch appropriate for campus and enterprise networks requiring strong, secure, and scalable connectivity. Equipped with 24 Gigabit Ethernet ports and 4 10G SFP+ uplinks, it provides high-speed data transfer and flexibility to meet various applications of networking.

Key Specifications

Model: RG-S5350-24GT4XS-E

Fixed Ports:

• 24 × 10/100/1000BASE-T RJ45 ports
• 4 × 1G/10G SFP+ uplink ports

Switching Capacity: 128 Gbps

Forwarding Rate: 96 Mpps

MAC Address Table: 32,000 entries

IPv4 Unicast Routes: 8,000 (upgradeable to 12,000 with license)

IPv6 Unicast Routes: 4,000

Access Control Entries (ACEs):

• Ingress: 3,500
• Egress: 1,500

Dimensions (W × D × H): 442 mm × 220 mm × 43.6 mm

Weight: 3.1 kg

Operating Temperature: 0°C to 45°C

Storage Temperature: -40°C to +70°C

Power Input: AC 100V to 240V, 50/60Hz

Maximum Power Consumption: 25 W (w/o PoE load); 40 W (full PoE load)

Features & Benefits

• High-Density Gigabit Access: Provides 24 Gigabit Ethernet ports for ultimate-speed connectivity to end devices.
• 10G Uplink Flexibility: Four SFP+ ports provide 1G/10G speed, enabling high-bandwidth uplinks and network aggregation.
• Advanced Layer 3 Routing: Provides static routing, RIP, OSPF, IS-IS, and BGP to efficiently manage network traffic.
• Comprehensive Security Features: Provides IEEE 802.1X authentication, IP Source Guard, Dynamic ARP Inspection, and DHCP snooping to protect against unauthorized access and network attacks.
• Strong Management Capability: Supports SNMP, web-based GUI, and CLI to manage networks with flexible and ease-of-use methods.
• Energy Efficiency: It contains advanced fan speed management and low-energy components to decrease power consumption and operating noise levels.
• Improved Reliability: It contains ESD protection (8 kV air discharge, 6 kV contact discharge) and IP40-rated ingress protection to be more ruggedized

Applications

• Enterprise Core or Aggregation Layer: Ideal for deployment as a core or aggregation switch in medium to large enterprise networks.
• Campus Networks: Ideally suited for high-speed needs and advanced features in schools and universities.
• Data Centers: Provides enterprise-class, reliable, and scalable data center connectivity for high-density server deployments in data center networks.

Package Contents

• 1 × RG-S5350-24GT4XS-E Switch
• 1 × Power Cord
• 1 × Console Cable
• 1 × Rack Mount Kit
• 1 × Quick Installation Guide
