1000MBPS Single mode fiber converter tx:1310

The SODOLA Gigabit Ethernet Media Converter is intended to seamlessly integrate copper-based Ethernet networks and fiber optic infrastructures. With a 1310nm Single-Mode SFP module, it can support the conversion of 10/100/1000Base-T Ethernet signals to 1000Base-LX fiber signals with a transmission distance of up to 20 kilometers.

Key Specifications

Brand: SODOLA

Model: Gigabit Ethernet Media Converter

Media Type: SingleMode Fiber (Dual LC)

Ethernet Port: RJ45, 10/100/1000Base-T

Fiber Port: Dual LC, 1000Base-LX

Wavelength: TX: 1310nm, RX: 1310nm

Distance: Maximum 20 km (12.4 miles)

Data Rate: 10/100/1000 Mbps

Connector Type: RJ45 (Ethernet), LC (Fiber)

Power Supply: External Adapter

Features & Benefits

• Seamless Conversion: Conveniently converts Ethernet signals to fiber, enabling long-distance network extensions.
• High-Speed Performance: Gigabit Ethernet speeds supported, ensuring fast data transmission.
• Extended Reach: Utilizes SingleMode fiber to achieve distances of up to 20 km, ideal for large campus networks.
• Plug-and-Play: No driver installation required; simple setup for instant deployment.
• Robust Design: Built to withstand several environmental conditions to work with assurance.

Applications

• Network Expansion: Suitable for use in network coverage expansion in large buildings or campuses.
• Data Center Interconnection: Connects remote data centers over long distances.
• Industrial Application: Suitable for use in factory automation systems requiring long-distance communication.
• Surveillance Systems: Connects IP cameras and monitoring equipment over long distances.

Technical Insight

This media converter is SingleMode fiber dependent, which allows for higher bandwidth and longer transmissions than MultiMode fiber. 1310nm wavelength is applied in long-distance communication due to lower attenuation and dispersion characteristics.

Dimensions & Weight

• Dimensions: Approximately 90mm x 70mm x 25mm
• Weight: Approximately 200g
